The Keysight DP0033A is a 200 MHz high-voltage differential probe with a 600 Vrms CAT III rating, designed for safe and precise differential voltage measurements in fast-switching environments with high common-mode voltages. It supports voltages up to ±3,000 V, making it ideal for demanding applications.

Key Features:

200 MHz bandwidth for high-speed signal analysis

±3,000 V differential voltage range (DC + AC peak)

Auto-switchable attenuation ratios: 1,000:1 / 100:1

High input impedance: 20 MΩ || 2 pF for minimal circuit loading

Excellent DC common mode rejection: >80 dB

UL safety-certified for reliable operation

AutoProbe interface with 1 MΩ input for seamless oscilloscope integration

Included Accessories:

DP0040-68702 – 1 m extension lead set

DP0040-68703 – Jaws test clip set

DP0040-68704 – Hook test clip set

DP0040-68705 – 3,000 V alligator test clip set

Compatibility:

The DP0033A is fully compatible with Keysight oscilloscopes featuring a 1 MΩ AutoProbe interface, including:

InfiniiVision 3000X, 4000X, 6000X, and HD3 Series

Infiniium EXR and MXR Series

This high-performance probe ensures accurate differential voltage measurements with industry-leading safety and signal integrity.
