Support hoisting grips are used to distribute the force introduced into a cable when hoisted using a winch, as is usually the case when cable size and/or length lead to an overall weight that cannot be operated manually.

Hoisting grips consist of a wire mesh and hold the cable size; the closed weave version – used when the top connector is installed after the cable is hoisted – and the open weave version – used in cases where the top connector is installed prior to hoisting the cable. Also in the latter case the closed version might be used if it shall be left on the cable replacing the top cable clamp.

Support Hoisting Grips

Open weave and closed weave design

Support clamp included with open weave grips

Custom sizes hoisting grips available upon request

Open Weave Hoisting Grips

Click Part # to Purchase

Part #                              Description

RFX-HGO-0.375SS        Open Weave Hoisting Grip for 3/8” Coaxial Cable

RFX-HGO-0.5SS             Open Weave Hoisting Grip for 1/2” Coaxial Cable

RFX-HGO-0.875SS        Open Weave Hoisting Grip for 7/8” Coaxial Cable

RFX-HGO-1.25SS        Open Weave Grip for 1-1/4” Coaxial Cable

RFX-HGO-1.625SS        Open Weave Grip for 1-5/8” Coaxial Cable

Closed Weave Hoisting Grips

Click Part # to Purchase

Part #                          Description

RFX-HGC-0.375SS     Closed Weave Hoisting Grip for 3/8” Coaxial Cable

RFX-HGC-0.5SS         Closed Weave Hoisting Grip for 1/2” Coaxial Cable

RFX-HGC-0.875SS     Closed Weave Hoisting Grip for 7/8” Coaxial Cable

RFX-HGC-1.25SS        Closed Weave Hoisting Grip for 1-1/4” Coaxial Cable

RFX-HGC-1.625SS      Closed Weave Hoisting Grip for 1-5/8” Coaxial Cable
